Specifications
| Permissible gross vehicle weight (t) | 4,5 |
|---|---|
| Max. payload (kg) | 1.500 (optional 2.400) |
| Max. extension length (m) | 34,0 (optional 36,0) |
| Hook heigh max. (m) | 32,6 (34,7) |
| Working height up to boom (m) | 23,4 |
| Boom extendable (m) | 4,9 / 8,8 / 11,1 (opt. 13,1) |
| Boom payload (kg) | 2.400 / 1.500 / 800 / 500 / (250) |
| Main mast angle (degrees) | 85 |
| Boom angle (degrees) | 162 |
| Pivoting range (degrees) | +/- 310 |
| Hook speed (m/min) | 50 |
