View technical specifications

Top Features

  • Maximize productivity
  • Help reduce human error
  • Simplify maintenance and repairs
  • Protect employees and property from harm

or Call us on: 0844 770 6774


Maximum Load Capacity135 kg
Intelli-Grip® TechnologyAutomatic self-testing ensures lifter is ready for use, every lift. Colour display provides critically relevant information at a glance. Anticipates threats and alerts operator beforehand with clearly visible and audible warnings. Continuously monitors battery and prevents lifter from attaching to loads if energy is hazardously low. Multiple alarm levels plainly identify the severity of hazards.
Load MovementManual rotation, 180° edgewise, with locking in three positions. Manual tilt, 90° between upright and flat, with automatic latching in upright position (in centre rotation position, as shown on drawings).
Standard Operating Power12 volts DC, 5 amps
Dual Vacuum SystemFeatures two completely independent vacuum circuits. Provides vacuum system redundancy. Limits possibility of a catastrophic failure. Reduces chance of harm to personnel or equipment.
Lifter Weight36 kg
Standard Pad Spread610 mm x 280 mm
Number / Size of Pads2 / 250 mm dia. lipped vacuum pads
Design StandardsASME B30.20 (BTH-1 Design Category "B", Service Class "0") AS 4991-2004 CE
