Specifications
| Lifting cap. arm in/out | 380/210 kg - 840/460 lbs. |
|---|---|
| Lifting height | 2,700 mm / 106 in. |
| Extension of arm | 500 mm / 20 in. |
| Tip from horizontal | 45o back / 105o fwd. |
| Side shift | 100 mm / 4 in |
| Charging voltage | 230 V / 110V |
| Charging time | Approx. 8 hrs. |
| Battery (2 x 12V) | 2 x 60 Ah |
| Running period | Up to 10 hrs. |
| Rear-wheel drive | 700 W DC |
| Brake | Electro-magnetic |
| Suction pads | 4 x Ø300mm / 4 x Ø12 in. |
| Width | 650 mm / 26 in |
| Curb weight | 570 kg / 1,260 lbs. |
